Product Details:
Payment & Shipping Terms:
|
| Cover: | Black Plastic | Wire: | Copper |
|---|---|---|---|
| Pins: | 4 Pins | Contact: | Copper |
| Waterproof: | Sealed | Led Light: | No Light |
| OE: | 68055795AA 95220-2S000G | ||
| High Light: | automotive micro relay,toyota air conditioner relay |
||
Miniature Conversion Relay Toyota Relay 12V 24V 4P pure copper wire automobile system
1. How to choose a good relay
Its quality mainly depends on the material and technology, choose a silver contact point makes the working life much longer, and machine core use pure copper wire, 30 and 87 pins use copper material too, then the relay can be used for 5-8 years. If add one more braided wire ,the power will be larger, so as the working life . If need matching with the OEMs , you can choose a larger particles of silver contact , using longer, but the price will be higher too .Our company has been established for over ten years. More than 100 kinds of products in our factory production , almost contain all car relays and flasher, welcome to consult.
2.Parameter
| Characteristics | |
| Contact Form | 1A |
| Contact material | Silver Alloy |
| Current type | 30A 14VDC |
| Max Switching Voltage | 75V |
| Max Switching Current | 30A |
| Max Switching Power | 420W |
| Contact Resistance Voltage Drop | <100Ω |
| Electric life | 1000000ops |
| Mechanical life | 10000000 ops |
| Ambient temperature | -40°C~+85°C |
| Storage Temperature | -40°C~+85°C |
| Construction | Waterproof or Dust cover |
| Weight | 26g |
3. Excellent production equipment
4. Related Products
5. Main export market
Mid east , North America , Southeast Asia , South America , Africa ...
6. Guarantee
To make you rest assured about the after-sale,we would like to provide one-year quality guarantee.10000times life time .
