Product Details:
Payment & Shipping Terms:
|
| Kind: | Relay | Voltage: | 12V |
|---|---|---|---|
| Dimension: | 1.57 X 1.57 X 2.36 Inches | OE: | 033201107 / 0986332020 |
| Pins: | 5 | Fit: | Universal |
| Weight: | 23g | ||
| High Light: | single pole double throw relay dpdt,12V spdt relay,12V single pole double throw relay |
||
1. Specification
This relay is a General-purpose Relay with DC coil, has SPST-NO (1NO) AgNi0.15 contact, cover with mounting bracket protection category. High resistance to inrush current. High continuous DC current capacity.
| Contact Material | Silver Alloy |
| Contact Resistance | 100mΩ Max |
| Operate Time | 10msec.Max |
| Release Time | 100mΩ Min.(DC500W) |
| Insulation Time | 100mΩ Min.(DC500W) |
| Electrical Life | 10000000 times |
| Mechanical Life | 100000times |
| Temperature | -40℃~+125℃ |
| Weight | Around 23g |
| Coil& Contacts Dielectric Strength | AC 500V, 50/60Hz 1min |
| Open Contacts Dielectric Strength | AC 500V, 50/60Hz 1min |
2.Details
Application: Reverser, Fan, Headlight, Air conditioning, Brake, Fuel Flow Meter, Starter
3.Guarantee
To make you rest assured about the after-sale,we would like to provide one-year quality guarantee.
4.Sample Policy
To enhance more understanding of each other and our products,we’d like to provide the sample free to you for testing.
5.Terms of payment
T/T 30% as deposit, and 70% before delivery. We'll show you the photos of the products and packages before you pay the balance.
6. Delivery time
Generally, it will take 20 to 45 work days after receiving your advance payment. The specific delivery time depends on the items and the quantity of your order.
We are the manufacturer of auto parts for more than 10 years, definitely we can provide you with good quality, good price and good service.
